TARGA 3000 Configuration Cookbook
11/25/2002
30
4.4 Tyan S1867 Thunder 2500
http://www.tyan.com
Tested Configuration
- BIOS version dated 04/14/00
- Board version 2.1 Ultra2 SCSI (version 2.2, with
optional Ultra160m SCSI was not tested)
+ Two Pentium III 667MHz "Coppermine" 133 Mhz
FSB
+ 512 MB PC-133 SDRAM
+ ATI Rage 128 Pro PCI 16MB display adapter
+ Adaptec 29160 SCSI host adapter BIOS v2.55.0
+ Seven Quantum Atlas 10K 9WLS Ultra160m 9 GB
drives
BIOS Settings:
Setup Values with the following changes:
Power Management is disabled
Performance Rating
3 streams YUV uncompressed
Slot Positions
AGP: empty (see TA note 2)
PCI 1: ATI Rage 128 Pro PCI
PCI 2: Adaptec 29160 SCSI
PCI 3: TARGA 3000
PCI 4: TARGA alternative
PCI 5: SCSI alternative
PCI 6: empty
ISA 1: empty
Technical Advisories
1. Consult Certified Memory Vendors
for specific
memory chips that have passed Tyan Engineering
tests. Note: Silicon Tech memory can be obtained by
contacting Simple Technology, Inc.
2. DMA between PCI and AGP is unresolved on this
board. A PCI graphics adapter is required.
3. Install both SCSI host adapter and TARGA in
either +3.3V or +5.0V slots. Operating across these
two busses will severely impact performance. PCI
slots 1,2,3 and 6 are 64-bit 5.0V 33MHz slots. Slots
4 and 5 are 64-bit 3.3V 66MHz PCI slots.
4. PCILOCK Boot Option
Motherboard Specifications and Features
Processor Information
· Dual Intel Slot 1
· Pentium III 450 - 933 MHz
· Two on-board VRMs (VRM 8.4 spec)
· Front Side Bus Support for 100 / 133 Mhz
Expansion Slots
· One 2x / Pro AGP slot
· Four 64-bit/33 MHz PCI slots (5V Only)
· Two 64-bit/66 MHz PCI slots
· One 16-bit ISA slot (shared w/ one PCI)
· One shared, seven usable slots
Chipset Information
· ServerWorks ServerSet III HE 4-chip solution
· SMC 37B787 Super I/O chipset
Main Memory
· Eight 168-pin Registered DIMM sockets
· Up to 8.0 GB PC100 / PC133 compliant Registered
SDRAM
· Supports ECC (72bit) memory modules
(Important: see Tyan's Recommended RAM list. This
board is truly selective.)
BIOS Information
· Phoenix BIOS on 2Mb Flash
Disk Drive & System I/O
· Two PCI bus mastering EIDE channels
· Supports EIDE CD-ROMs
· PIO Mode 3 & 4 (up to 16.6 MB/sec DTR)
· UltraDMA mastering mode support
Physical Dimensions
· Extended ATX footprint (12w x 13l.)
· Eight layer board
· Two 20-pin ATX power connectors
· Stacked Mouse/Keyboard ports
· Stacked (2) USB/RJ-45 with LED ports
· Stacked Line-In/Line-Out/Mic-In/MIDI ports
