Pioneer PDP-507XA User Manual

PDP-507XD
11
5678
56
7
8
C
D
F
A
B
E
(1) PACKING PARTS LIST
(2) CONTRAST TABLE
PDP-507XD/WYVIXK5, PDP-507XA/WYVIXK5 and WYV5 are constructed the same except for the following:
Mark
No. Description Part No.
> 1Power Cord (2 m) ADG1214
2 Remote Control Unit See Contrast table (2)
3 Battery Cover AZN2626
NSP 4 Dry Cell Battery (R06, AA) VEM1031
> 5Ferrite Core ATX1039
6 Binder Assy AEC1908
7 Cleaning Cloth AED1285
8 Operating Instructions See Contrast table (2)
(Italian, Spanish, Dutch)
9 Operating Instructions See Contrast table (2)
(English, French, German)
10 Block Diagram See Contrast table (2)
11 Caution Card See Contrast table (2)
12 Cleaning Caution See Contrast table (2)
NSP 13 Warranty Card ARY1114
14 Polyethlene Bag See Contrast table (2)
15 Vinyl Bag AHG1337
16 Vinyl Bag AHG1340
17 Pad (507 T-L) See Contrast table (2)
18 Pad (507 T-R) See Contrast table (2)
19 Pad (507 B-L) See Contrast table (2)
20 Pad (507 B-R) See Contrast table (2)
21 Power Cord Lid See Contrast table (2)
22 Under Carton (507) See Contrast table (2)
23 Upper Carton See Contrast table (2)
24 Mirror Mat See Contrast table (2)
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-507XD
/WYVIXK5
PDP-507XA
/WYVIXK5
PDP-507XA
/WYV5
2 Remote Control Unit AXD1532 AXD1540 AXD1540
8 Operating Instructions (Italian, Spanish, Dutch) ARC1562 ARC1564 ARC1563
9 Operating Instructions (English, French, German) ARE1428 ARE1430 ARE1429
10 Block Diagram ARY1189 ARY1189 Not used
11 Caution Card ARM1310 ARM1310 ARM1232
12 Cleaning Caution ARM1311 ARM1311 ARM1283
14 Polyethylene Bag AHG1326 AHG1326 Not used
17 Pad (507 T-L) AHA2558 AHA2558 AHA2538
18 Pad (507 T-R) AHA2559 AHA2559 AHA2539
19 Pad (507 B-L) AHA2560 AHA2560 AHA2540
20 Pad (507 B-R) AHA2561 AHA2561 AHA2541
21 Power Cord Lid AHC1087 AHC1087 AHC1085
22 Under Carton (507) AHD3498 AHD3498 AHD3473
23 Upper Carton (507XD) AHD3521 Not used Not used
23 Upper Carton (507XA) Not used AHD3499 AHD3522
24 Mirror Mat AHG1327 AHG1327 AHG1284

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
