3. In a case where normal backup data are not stored in the backup EEPROM because
the EEPROM on the DIGITAL Assy is defective, etc., and where manually adjusted
values are to be applied to the product
Note: In this section, it is assumed that settings for various items have been completed, using Factory menu or RS-232C
commands.
(1) Method using the Factory menu
1 Set various setting/adjustment values.
2 Proceed in the following steps.
(2) Method using the RS-232C commands
Issue the FAJ command.
3 Turn the power off.
Note:
When a DIGITAL Assy with an EEPROM in which adjustment data are stored is mounted, this step is not required after
manual adjustment. ("DIGITAL EEPROM: REPAIR" is not indicated.)
PANEL INFORMATION
ETC. (+)
BACKUP DATA : NO OPRT
Key Down 7th
Key Down
SET
Right
SET (5 sec)
DIGITAL EEPROM : NO OPRT
DIGITAL EEPROM : REPAIER

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
