Pioneer PDP-507XA User Manual

PDP-507XD
13
5678
56
7
8
C
D
F
A
B
E
(1) REAR SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-507XD/WYVIXK5, PDP-507XA/WYVIXK5 and WYV5 are constructed the same except for the following:
Mark
No. Description Part No.
1 SIDE KEY Assy AWW1133
2 SIDE Assy AWW1162
3 Filter CTX1054
4• • • • •
5 Side Input Panel (E) ANC2418
6 Function Button Base ANG2923
7 Side Input Shield ANK1834
8 Function Button Shield ANK1835
NSP 9 PCB Support AEC1288
10 • • • • •
11 Wire Saddle AEC1745
12 • • • • •
13 Locking Card Spacer AEC2019
14 • • • • •
15 Inner Grip Assy AMR3434
16 • • • • •
NSP 17 Name Label See Contrast table (2)
18 • • • • •
19 Bolt Caution Label See Contrast table (2)
20 Serial Seal AAX3143
21 • • • • •
22 Terminal Label A (E/T) See Contrast table (2)
23 Terminal Label C (E/T) AAX3339
24
Ter minal Label B50 (E/HT)
AAX3418
25 Terminal Panel B (50E) ANC2410
26 Function Button Panel AMB2906
27 Side Input Cover AMB2911
28 Function Button (E) AAC1565
29 Function Button Sheet (E) AAK2896
30 Input Cover Label E See Contrast table (2)
31 Rear Case (507) ANE1656
32 • • • • •
33 Screw (3 x 40P) ABA1332
34 Screw ABA1341
35 • • • • •
36 Screw AMZ30P060FTB
37 Screw AMZ30P080FTC
38 Screw APZ30P080FTB
39 Screw BPZ30P080FTB
40 Screw TBZ40P080FTB
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-507XD
/WYVIXK5
PDP-507XA
/WYVIXK5
PDP-507XA
/WYV5
NSP 17 Name Label (507XD) AAL2813 Not used Not used
NSP 17 Name Label (507XA) Not used AAL2815 AAL2814
19 Bolt Caution Label AAX3005 AAX3005 AAX3117
22 Terminal Label A AAX3337 AAX3398 AAX3332
30 Input Cover Label E AAX3396 AAX3396 AAX3375

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
