PDP-507XD
134
1234
1234
C
D
F
A
B
E
2 SIG Mode and Screen size (by User is displayed)
1st and 2nd characters : Resolutin of the input signal
3rd and 4th characters : Refresh rate of the input signal
5th character : Selection of the screen size
7 Input signal mode table for video signals (resolutions and V frequencies)
7 Input signal mode table for PC signals (resolutions and V frequencies)
7 Current selection of the screen size
Fv: Vertical Frequency, Fh: Horizontal Frequency
Fv: Vertical Frequency, Fh: Horizontal Frequency
: supported, : unsupported
1st to 4th Character Signal Type Fv (Hz) Fh (kHz)
10
50 SDTV*525i 60.000 15.750
60 SDTV*525i 60.000 15.750
20
50 SDTV*625p 60.000 31.500
60 SDTV*525p 60.000 31.500
30
50 HDTV*1125i 60.000 33.750
60 HDTV*1125i 60.000 33.750
40
50 HDTV*750p 60.000 45.000
60 HDTV*750p 60.000 45.000
50 24 HDTV*1125p 24.000 27.000
5th Character GUI Notation VIDEO PC Remarks
0 DOT BY DOT
1 4:3
¶¶
2 FULL (FULL1)
¶¶
3 ZOOM
4 CINEMA
5 WIDE
6 FULL 14:9
7 CINEMA 14:9
8 FULL2
1st to 4th Character Signal Type Fv (Hz) Fh (kHz)
C1 70 720 x 400 70.087 31.469
C2
60
640 x 480
59.940 31.469
72 72.809 37.861
75 75.000 37.500
C4
56
800 x 600
56.250 35.1556
60 60.317 37.879
72 72.188 48.077
75 75.000 46.875
C7
60
1024 x 768
60.004 48.363
70 70.069 56.476
75 75.029 60.023
C9 60 1360 x 768 60.015 47.712
