Adjustment assistance command
The Adjustment Assistance Command is combined and used with the Adjustment Command.
• The Adjustment Command + Adjustment Assistance Command ⇒ It addition/subtracts it from a present adjustment value.
Note: When the received command exceeds the range of the adjustment value, it changes to MAX/MIN.
• The adjustment command immediately before is made efficacy when only the adjustment command (addition/subtraction
command) is received alone after the adjustment command receptions completed, and it makes it to the value addition/
subtracted from a present adjustment value. However, it applies to the command when other commands are received.
• Kind of Adjustment Assistance Command (addition/subtraction command)
UP1 to UP9, UP0, UPF: 1 to 10 is added to a setting value.
UPF: It makes it to the maximum value ("VOL" command).
DW1 to DW9, DW0, DWF: 1 to 10 is subtracted a setting value.
DWF: It makes it to the minimum value ("VOL" command).
FWD: One Priset CH is previously advanced ("CHN" command).
REV: One Priset CH is returned in the front ("CHN" Command).
Send data to PDP system Receive data
STX ID Command Subcommand ETX STX Command Subcommand ETX
0x02 ∗∗ VOL UP1 0x03 0x02 VOL UP1 0x03

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
