Pioneer PDP-507XA User Manual

PDP-507XD
40
1234
1234
C
D
F
A
B
E
D1967, 1977 1SS302
D1971 UDZS15(B)
D1974 EP05FA20
D1976, 1978 1SS355
MISCELLANEOUS
L1930, 1940, 1950, 1960 ATH1199
L1970 ATH1199
RESISTORS
R1910, 1911 RS1/16SS220J
Other Resistors RS1/16S###J
CAPACITORS
C1910 CKSYB105K25
C1911 ACG1098
C1930, 1940, 1950, 1960 ACG1137
C1931, 1941, 1951, 1961 ACG1136
C1970 ACG1137
C1971 ACG1136
50 SCAN A ASSY
SEMICONDUCTORS
IC2801–2806 SN755870KPZT-P
D2801 CRH01
D2802–2807, 2809, 2811 1SS302
D2810 1SS355
MISCELLANEOUS
CN2801 AKP1261
CN2802 AKM1281
CN2803 AKP1306
RESISTORS
R2805, 2810, 2813, 2816 RAB4C221J
R2819, 2822 RAB4C221J
Other Resistors RS1/16S###J
CAPACITORS
C2801, 2802, 2811, 2812 ACG1088
C2803, 2813, 2823, 2833 CKSRYB105K6R3
C2805–2807, 2815–2817 CCSRCH220J50
C2808–2810, 2818–2820 CCSRCH151J50
C2821, 2822, 2831, 2832 ACG1088
C2825–2827, 2835–2837 CCSRCH220J50
C2828–2830, 2838–2840 CCSRCH151J50
C2841, 2842, 2851, 2852 ACG1088
C2843, 2853 CKSRYB105K6R3
C2845–2847, 2855–2857 CCSRCH220J50
C2848–2850, 2858–2860 CCSRCH151J50
50 SCAN B ASSY
SEMICONDUCTORS
IC2901–2906 SN755870KPZT-P
IC2907 TC7SH08FUS1
D2902–2908 1SS302
D2909 1SS355
MISCELLANEOUS
CN2901 AKM1281
CN2902 AKP1306
Mark No. Description Part No.
RESISTORS
R2903, 2908, 2911, 2914 RAB4C221J
R2917, 2920 RAB4C221J
Other Resistors RS1/16S###J
CAPACITORS
C2901, 2902, 2911, 2912 ACG1088
C2903, 2913, 2923, 2933 CKSRYB105K6R3
C2905–2907, 2915–2917 CCSRCH220J50
C2908–2910, 2918–2920 CCSRCH151J50
C2921, 2922, 2931, 2932 ACG1088
C2925–2927, 2935–2937 CCSRCH220J50
C2928–2930, 2938–2940 CCSRCH151J50
C2941, 2942, 2951, 2952 ACG1088
C2943, 2953, 2961 CKSRYB105K6R3
C2945–2947, 2955–2957 CCSRCH220J50
C2948–2950, 2958–2960 CCSRCH151J50
POWER SUPPLY UNIT
POWER SUPPLY UNIT has no service part.
Mark No. Description Part No.

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
