K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Now take the provided Pipistrel cooling system pipe and fit as shown in the photos below.
You can use the rubber hosing that came with the original coolant canister. You'll just
need to trim the hosing a little to the proper lengths.
 Place two strips of rubber hosing in between the cooling system pipe and the plastic
ventilation cover, just near the Pipistrel engine mount. This will make sure nothing
rattles due to vibrations. Use red paint on the screws to mark them as finished.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 131 of 267
