K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Now mount the black Pipistrel bracket which was provided with the kit. The throttle and
choke cable plate will eventually be bolted to this bracket.
 At this point you can also fit the temperature sensor screw at the top of the cooling
system pipe. Apply Loctite 577.
 Remount the manifolds using blue Loctite 243. Mark the bolts with red paint.
 Remove the spark plugs and check the electrode gap. It should measure 0.5 mm. Adjust
accordingly.
 Remount the spark plug, being sure not to tighten them too much because it could crack
or seize in the cylinder head. Use a torque wrench and tighten to 20 N.m.
 Mount the propeller control arm. Apply blue Loctite 243 to ensure it does not loosen.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 132 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
