K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Fit the 380mm hose to the fuel pump's inner spout using a 12mm hose clamp. Attach one end of
920mm hose to the fuel pumps outer spout. Feed the other end of the 920mm hose between cylinder
heads 1 and 2. Leave it there for future use.
 Clamp the distributor down using ties, but place a piece of foam underneath first.
