K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Mount the oil temperature sensor and the cylinder head temperature sensor as shown in the photos
below. Apply Loctite 577.
 You can start mounting the oil cooler by giving the two holes at the front of the crankcase
a nice chamfer. Then clean them up and fit the two Pipistrel extension bolts. Apply blue
Loctite 243.
 Fit two rubber stoppers onto the ends of the extension bolts. Shorten the threads a little
to ensure a good fit.
 Now you can mount the oil cooler.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 143 of 267
