• The lateral assembly push rod, which connects the two control sticks, is altered to
accomodate the autopilot. It has an arm that connects to the other end of the
servomotor's push rod. In order to ensure that this arm moves freely, you have to cut
away a bit of composite material from the support leg that stands between the cabin floor
and the fuselage. See the photos below to get an idea of how this is done.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 239 of 267
51.8 mm
63.6 mm
8.3 mm
8.1 mm
