User Manual of VDR-300NU
1.4 Product Specifications
Model VDR-300NU
Product Description 802.11n Dual Band Wireless VDSL2 Router
Hardware Specifications
LAN 4 x 10/100Base-TX, Auto-Negotiation, Auto MDI/MDI-X RJ45 port
WAN 1 x RJ-11
Interfaces
USB USB 2.0, Type-A, 5V DC/0.5A Output
Antenna
2.4GHz : 2 x 2.5dBi
5GHz: 2 x 2dBi
Button
1 x RESET button
1 x WPS button
LED Indicators PWR, DSL, LAN1-4, WLAN, WPS, Security
Dimensions (W x D x H) 180 x 145 x 54 mm
Weight
306g
Power 12V DC, 2A
Power Consumption 18W (not including power adapter)
Router Features
Internet Connection
Type
Shares data and Internet access for users, supporting the following
internet accesses:
 PPPoE
 Dynamic IP
 Static IP
VDSL Features
 ITU-T G.993.2 VDSL2
 Supports 8a,8b,12a,12b,17a,30a profile
 Supports G.vector
 Supports ATM and PTM
 Supports G.INP
ADSL Features
 T1.413i2, G.992.1
 G.dmt, G.992.2, G.lite
 G.992.3 (G.bis/ADSL2)
 G.992.5 (ADSL2+)
 ITU G.994.1 (G.hs)
 Annex L (Reach Extended ADSL2)
 Supports ATM forum UNI3.0, 3.1 and 4.0 permanent virtual circuits
(PVCs)
 Supports CBR, UBR, VBR-rt, VBR-nrt
 Supports multiple PVCs
 Supports ITU-T i.610F4/F5 OAM
Bridging Features
 Self-learning bridge (IEEE 802.1D Transparent Bridging)
 At least 64 learning MAC addresses
 Supports IGMP snooping
14
