User Manual of VDR-300NU
If you want to remove this Interface, please select the Remove check box and click Remove.
 PTM Interface
Choose Advanced Setup > Layer2 Interface > PTM Interface, and the following page appears. On this
page, you can add or remove to configure PTM WAN Interfaces.
Figure 5-2-4
Click Add and the following page appears.
Figure 5-2-5
On this page, you can select scheduler for queues of equal precedence and enter the queue value. Click
Apply/Save to save configuration.
 ETH Interface
Choose Advanced Setup > Layer2 Interface > ETH Interface and the following page appears. On this
page, you can add or remove to configure ETH WAN Interfaces.
38
