User Manual of VDR-300NU
Management
 Device Configuration, Management and Update
 Web based GUI
 Localization support
 Embedded web server
 Download image via HTTP, TFTP client, TFTP server, FTP server
 Command Line Interface via serial port, telnet, or ssh
 Menu-driven CLI via serial port or telnet
 Universal Plug and Play (UPnP) Internet Gateway Device (IGDv1.0)
 WAN Management Protocol (TR-069)
 SNMP v1/v2
 PSI configuration file upload and download
 Date/time update from SNTP Internet Time Server
Wireless Interface Specifications
Wireless Standard IEEE 802.11a/b/g/n
Frequency Band
2.4GHz: 2.412~2.484GHz
5GHz: 5.180~5.825GHz
Modulation Schemes
 802.11g: 64QAM, 16QAM, QPSK, BPSK, DSSS
 802.11b: CCK, DQPSK, DBPSK
 HT20 and HT40: 64 QAM, 16QAM, QPSK, BPSK
802.11n(40MHz):
up to 300 Mbps
802.11n(20MHz):
up to 144.4 Mbps
802.11g:
54, 48, 36, 24, 18, 12, 9, 6 Mbps per channel, auto fallback for
extended range
802.11b:
1, 5.5, 2, 1 Mbps per channel, auto fallback for extended range
Data Transmission
Rates
802.11a:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
RF Power
2.4GHz:
11b: 18±1.5dBm
11g: 14.5±1.5dBm
11n(20M): 16.5±1.5dBm (MCS0~3)
14.5±1.5dBm (MCS4~7)
16.5±1.5dBm (MCS8~11)
14.5±1.5dBm (MCS12~15)
11n(40M): 14±1.5dBm (MCS0~3)
12.5±1.5dBm (MCS4~7)
14±1.5dBm (MCS8~11)
12.5±1.5dBm (MCS12~15)
Wireless Data
Encryption
64/128-bit WEP, WPA-PSK, WPA2-PSK, 802.1x encryption, and
WPS PBC
