User Manual of VDR-300NU
On this page, you may add or remo
ve an entry of port triggering. Click the Add button to display the
following page.
Figure 5-2-46
Object Description
Use Interface
Select an interface that you want to configure
Select an
application
Select a proper application in the drop-down list.
Custom application
Enter a new service name to establish a user service type.
Trigger port Start
The start port number that LAN uses to trigger the open port.
Trigger port End
The end port number that LAN uses to trigger the open port.
Trigger Protocol
Select the application protocol. You may select TCP/UDP, TCP, or
UDP.
Open Port Start
The start port number that is opened to WAN.
Open Port End
The end port number that is opened to WAN.
Open Protocol
Select the proper protocol that is opened to WAN. You may select
TCP/UDP, TCP, or UDP.
65
