User Manual of WNAP-7320
-26-
Object Description
Internet Configuration
 Connected Type
Displays current Internet connection type.
 Connected Status
 Disconnected: Indicates that the Ethernet cable from your
ISP side is / is not correctly connected to the WAN port on
the AP or the AP is not logically connected to your ISP.
 Connecting: Indicates that the WAN port is correctly
connected and is requesting an IP address from your ISP.
 Connected: Indicates that the AP has been connected to
your ISP.
 WAN IP
Displays WAN IP address.
 Subnet Mask
Displays WAN subnet mask.
 Default Gateway
Displays WAN gateway address.
 Primary Domain Name
Server
Displays WAN DNS address.
 Secondary Domain
Name Server
Displays WAN DNS address.
 MAC Address
Displays AP’s WAN MAC address.
LAN Configuration
 LAN IP Address
Displays LAN IP address.
 LAN Netmask
Displays LAN subnet mask.
 MAC Address
Displays AP’s LAN MAC address.
System Info
 Firmware Version
Displays current F/W version.
 System Time
Displays the System Time.
 Operation Mode
Displays current Operation Mode.
 Wireless MAC Address
Displays AP’s Wireless MAC address.
 Statistics
This section allows you to view the AP’s Statistics listed below:
