User Manual of WNAP-7320
-15-
3.3 Installing the AP
Please install the AP according to the following steps. Don't forget to pull out the power plug and keep your
hands dry.
Step 1. Push the latch in the bottom of WNAP-7320 to remove the sliding cover.
Figure 3-1
Step 2. Plug the RJ-45 Ethernet cable into the PoE LAN Port of WNAP-7320.
Figure 3-2
RJ-45 8P8C Ethernet cable is required.
