User Manual of WNAP-7320
-27-
Figure 5-1-2
Object Description
Memory
 Memory Left/
Memory Total
Displays the retain memory and total memory.
WAN/LAN
 WAN Rx packets
Displays the real-time packets received from WAN port.
 WAN Rx bytes
Displays the real-time bytes received from WAN port.
 WAN Tx packets
Displays the real-time packets transmitted from WAN port.
 WAN Tx bytes
Displays the real-time bytes transmitted from WAN port.
 LAN Rx packets
Displays the real-time packets received from LAN port.
 LAN Rx bytes
Displays the real-time bytes received from LAN port.
 LAN Tx packets
Displays the real-time packets transmitted from LAN port.
 LAN Tx bytes
Displays the real-time bytes transmitted from LAN port.
 DHCP Clients
This section displays a DHCP dynamic client list, which includes MAC address, IP address, and lease time info.
