User Manual of WNAP-7320
-73-
5.6.1.3. Wireless Mode – WDS Repeater
Figure 5-6-3
The page includes the following fields:
Object Description
 Wireless Mode
Click to select Wireless Mode from pull down menu.
There are 4 options available:
 Access Point:
This mode allows wireless clients or Stations(STA) to access
 WDS Access Point:
This mode enables the wireless interconnection of Access Point
in an IEEE802.11 network .and accept wireless clients at the
same time.
 WDS Repeater:
Set to this mode to enable the wireless access point repeat the
signal of root access point using WDS.
 WDS Client:
Set to this mode to enable wireless client using WDS to connect
to the WDS Access Point.
 Root AP MAC Address
(optional)
Fill out the Root AP’s MAC Address enable it to connect to the Root
AP using WDS.
 Country Code
Set your country code by clicking the “Set Country Code”.
