User Manual of WNAP-7320
-45-
Step 8. Configure the wired client’s TCP/IP setting to “Obtain an IP address automatically”.
Figure 5-3-31
After got the IP assigned by the WNAP-7320, ping the DNS server to check whether internet connection is
reachable.
5.3.3.4. Client Bridge (Slave AP Bridge)
In the Client Bridge Mode, the WNAP-7320 function likes a wireless adapter. Connected to an Access Point
wirelessly and surf internet whenever you want. Using Site Survey to scan all the Access Point within the range
and configure its SSID and Security Password to associate with it.
1. Connect the LAN port of WNAP-7320 to the POE port of the PoE Injector with an Ethernet cable.
2. Connect the PC to the LAN port of the PoE Injector with an Ethernet cable.
3. Plug one end of the power cord into the PoE Injector, and the other end in electrical socket.
4. Go to “Advanced-> Operation Mode” to configure it to Client Bridge Mode.
