Planet WNAP-7320 - Advanced Routing

User Manual of WNAP-7320
-67-
5.5.4 Advanced Routing
Figure 5-5-12
The page includes the following fields:
Object Description
 Destination
The IP address of packets that can be routed.
 Type
Defines the type of destination. ( Host: Signal IP address / Net: Portion
of Network )
 Gateway
Defines the packets destination next hop
 Interface
Select interface to which a static routing subnet is to be applied
 Comment
Help identify the routing
 Dynamic Routing
Protocol
Enable or disable the RIP (Routing Information Protocol) for the
WAN or LAN interface.
It supports RIP v1 and v2.
