Planet WNAP-7320 User Manual

User Manual of WNAP-7320
-6-
1.4 Product Specification
Product
WNAP-7320
5GHz 300Mbps 802.11a/n Wireless Outdoor Access Point
Hardware Specifications
Standard support
IEEE 802.11a/n Wireless LAN
IEEE 802.11i Wireless Security
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Ethernet
IEEE 802.3x Flow Control
Memory
32 Mbytes DDR SDRAM
8 Mbytes Flash
Interface
Wireless IEEE802.11a/n, 2T2R
LAN: 1 x 10/100Base-TX, Auto-MDI/MDIX
WAN: 1 x 10/100Base-TX, Auto-MDI/MDIX
Antenna
Built-in 14dBi Dual-Polarization Antenna
- Horizontal: 45 degree
- Vertical: 60 degree
Wireless RF Specifications
Wireless Technology
IEEE 802.11a
IEEE 802.11n
Data Rate
IEEE 802.11a: 54, 48, 36, 24, 18, 12, 9 and 6Mbps
IEEE 802.11n (20MHz): up to 150Mbps
IEEE 802.11n (40MHz): up to 300Mbp
Media Access Control CSMA / CA
Modulation
Transmission / Emission Type: OFDM
Data modulation type: OFDM with BPSK, QPSK, 16-QAM, 64-QAM
Frequency Band 5.180GHz ~ 5.825GHz
5.180GHz CH36 5.580GHz CH116
5.200GHz CH40 5.600GHz CH120
5.220GHz CH44 5.620GHz CH124
5.240GHz CH48 5.640GHz CH128
5.260GHz CH52 5.660GHz CH132
5.280GHz CH56 5.680GHz CH136
5.300GHz CH60 5.700GHz CH140
5.320GHz CH64 5.745GHz CH149
5.500GHz CH100 5.765GHz CH153
5.520GHz CH104 5.785GHz CH157
5.540GHz CH108 5.805GHz CH161
5.560GHz CH112 5.825GHz CH165
Operating Channel
*The above 24 channels are defined in theory. The actual application will vary
depends on the regulation in different regions and countries.
RF Output Power IEEE 802.11a: 27 ± 1dBm
