User Manual of WNAP-7320
-57-
Figure 5-5-2
The page includes the following fields:
Object Description
WAN Connections
Select Cable/Dynamic IP (DHCP) from the list.
Host Name
This option specifies the Host Name of the AP Router.
Primary DNS Server
(Optional) Enter the DNS IP address in dotted-decimal notation
provided by your ISP.
Secondary DNS Server
(Optional) Enter another DNS IP address in dotted-decimal
notation provided by your ISP.
5.5.1.3. PPPoE (ADSL)
If local ISP provides a PPPoE connection, choose PPPoE (ADSL) and fill the necessary parameters below.
