User Manual of WNAP-7320
-41-
1. Connect the LAN port of WNAP-7320 to the POE port of the PoE Injector with an Ethernet cable.
2. Connect the PC to the LAN port of the PoE Injector with an Ethernet cable.
3. Plug one end of the power cord into the PoE Injector, and the other end in electrical socket.
4. Go to “Advanced-> Operation Mode” to configure it to AP Bridge Mode.
Figure 5-3-23
In this mode, the Wireless interface of the WNAP-7320 works as the WAN port.
To configure the Wireless Settings of AP Bridge Mode, please refer to the section 5.6 Wireless Settings
.
5.3.3.3. Client Router (WISP)
In the Client Router Mode, the WNAP-7320 has DHCP Server build inside that allows many LANs automatically
generate an IP address to share the same Internet. Connect an AP/WISP Wirelessly and connect to LANs via
wired. Client Router Mode is act completely opposite to the AP Router Mode.
