User Manual of WNAP-7320
-53-
Figure 5-4-5
The page includes the following fields:
Object Description
 QoS Setup Select Enable to enable the QoS function.
 Upload Bandwidth
Set the limit of total upload bandwidth in kbits. To disable
upload bandwidth limitation, input ‘0’ here.
 Download Bandwidth
Set the limit of total download bandwidth in kbits. To disable
download bandwidth limitation, input ‘0’ here.
 Target Set the target of QoS rule.
 Source IP
Specify the local (source) IP address that will be affected by
this rule. Please input the starting IP address in the left field,
and input the end IP address in the right field to define a range
of IP addresses, or just input the IP address in the left field to
define a single IP address.
