Operating space (if only wet milling used)
If only wet milling is used, the milling unit must be positioned for operation as
shown in the figure below; distance of 1 meter (40 inches) in front, 30 cm (12
inches) on left and right sides and 10 cm (4 inches) on the back side of the
unit must be available as a minimum.
21.3.2 Service and maintenance space requirements
Before service and maintenance works the milling unit must be positioned
as shown in the figure below. There must be a safety distance of 1 meter
(40 inches) around the machine to guarantee an unobstructed area in the
workplace, so that the unit is freely accessible from all sides during service
and maintenance work.
21 Technical information
User's manual Planmeca PlanMill 60 S 97
