• Cooling liquid 1000ml (10036920)
8.3 Milling tools
The tools approved by Planmeca for use in the Planmeca PlanMill 60 S
milling unit are listed in the table below.
WARNING
Only use tools that are approved by Planmeca or that have been
retrospectively approved. If unapproved tools are used there is a risk of
serious injury and substantial damage.
Please contact your local Planmeca dealer for the approval of other tools.
In order to process work-pieces, the milling unit must be equipped with at
least one tool. The appropriate and ready-ringed tools for the direct change
holder are available from your local Planmeca dealer.
Tool
numbe
r
Diameter/geometry Material(s) to
be used with
Name on the user
interface
2 2.0 mm / Radius Ti 2.0 mm Ti Radius
3 1.5 mm / Radius Ti 1.5 mm Ti Radius
4 1.0 mm / Radius Ti 1.0 mm Ti Radius
7 2.0 mm / Radius CoCr 2.0 mm CoCr Radius
8 1.5 mm / Radius CoCr 1.5 mm CoCr Radius
9 1.0 mm / Radius CoCr 1.0 mm CoCr Radius
11 2.5 mm / Radius PMMA/Wax 2.5 mm PMMA-Wax
Radius
12 1.0 mm / Radius PMMA/Wax 1.0 mm PMMA-Wax
Radius
13 2.5 mm / Radius Zr/Al 2.5 mm Zr-Al Radius
14 1.0 mm / Radius Zr/Al 1.0 mm Zr-Al Radius
15 0.6 mm / Radius,
conical shaft
Zr/Al/
PMMA/Wax
0.6 mm Zr-Al-PMMA-
Wax Radius
17 1.5 mm / toric long shaft Zr/Al/
PMMA/Wax
1.5 mm Zr-Al-PMMA-
Wax SHAFT
21 2.5 mm / Radius Glass ceramic 2.5 mm ceramic Radius
22 1.0 mm / Radius Glass ceramic 1.0 mm ceramic Radius
23 0.6 mm / Radius,
conical shaft
Glass ceramic 0.6 mm ceramic Radius
31 3.0 mm / shaft milling
tool
PMMA 3.0 mm shaft milling
tool long
