4. Loosen the clamping screws of the clamping ring (1) (do not remove)
using a 3 mm Allen key.
5. Remove the clamping ring by turning it in a clockwise direction to the
right.
6. Remove the workpiece.
7. Close the protective door.
16 Operating milling unit
70 Planmeca PlanMill 60 S User's manual
