Planmeca Proline EC X-ray unit G-1
Chapter
Technical Manual
G TROUBLESHOOTING
1 SERVICE MODE SIGNALS
Please refer to section “SERVICE MODE KEYBOARD FUNCTIONS” on page B-6 for details.
This mode provides helpful information when tracing sensor and switch signals, since the sig-
nals can be viewed here.
2 ERROR MESSAGES
Please refer to sections “ERROR MESSAGES” on page C-2 and “ERROR MESSAGE
EXPLANATIONS” on page C-4 for details. These error messages make fault finding easier.
Also the list of the last 50 error occurrences is of great help, refer to section “Error history dis-
play” on page B-12 how to display the error list.
