BOOKLET MAKER INSTALLATION
4. InstalltheShiftTrayPlate[E]ontothenisher(use x 4 counter screws
from installation kit).
5. InstalltheExitTrayPlate[F]ontothenisherexittray(use x 4 from instal-
lation kit).
[E]
[F]
