Plockmatic BK5030 - Page 18

1-11
November 2012
Booklet Maker
Installation
BOOKLET MAKER INSTALLATION
1. Remove the four screws on Finisher Rear Cover [A].
2. Using the screws Install the Docking Assembly [B] as shown in second picture.
Docking assembly
[B]
DS5030 Finisher
[A] ( x 4)
