Setting up Belt Stacker for Straight Mode
Adjust the stacking with belt speed
selector.
Adjust Side Guides to their
outermost position by loosening
knobs [A].
[A]
[A]
[B]
1 Adjust Side Guides to their
outermost position by loosening
knobs [A].
2 Adjust the stacking with belt speed
selector [B].
Setting up Belt Stacker for straight mode
