Plockmatic BLM 35 - Specifications; Machine Specifications Overview

97
8. Specication
Machine Specications
Rotate Crease Trim Module (option)
Specications Remarks
Speed Same as BLM35/50 Booklet Maker
Standard Paper Sizes Same as BLM35/50 Booklet Maker
Paper Size Minimum (Out) Same as BLM35/50 Booklet Maker
Paper Size Maximum (Out) Same as BLM35/50 Booklet Maker
Paper Width Maximum (In) 330mm 5mm bleed trim will auto-
matically be turned on
Paper Weight (Minimum) Same as BLM35/50 Booklet Maker
Paper Weight (Maximum) Same as BLM35/50 Booklet Maker Above 300gsm limited
performance with some
media
Rotator (optional)
Rotation is only possible within
the interval
Width (cross process direction)
min. 275mm. (10.9”).
Width (cross process direction)
max. 325mm. (12.7”).
Length (process direction)
min. 205mm. (8.1”).
Length (process direction)
max. 232mm. (9.1”).
Creaser
Tools
Fine tool
Coarse tool
Stock < 120 gsm
Stock > 120 gsm
(gsm =grams per sq. meter)
Bleed Trimmer
Minimum bleed trimming
Maximum bleed trimming
Max asymmetric bleed trimming
5 mm
30 mm
±5 mm
On each side of the sheet
Input / Output Sheets Same as BLM35/50 Booklet Maker
Input / Output Sheets Same as BLM35/50 Booklet Maker
Off-line Use Not possible
Weight 210kg/463lb
Dimensions (W x D x H) 710 x 860 x 1080 / 28 x 33.8 x 42.5”
(incl. 105mm / 4” waste transport)
Power Source 100 - 230V ±10% 50-60Hz
Power Consumption 300W Continuous operation
400W Max
