Plockmatic BLM 35 - Module Misfeeds; RCT Module Misfeeds

62
5
[B]
[A]
Bafe A
Bafe D
Infeed “A” area and exit “D” area
1 Open the RCT top cover.
2 Lift up bafes “A” and “D” if needed.
3 Remove any misfeed(s).
4 Lower bafes “A” and “D” to normal position
5 Misfeed(s) in the trimmer area are rolled out by rotating the rubber surfaced pinch
roller [A].
6 Close the top cover.
WARNING
Do not put your ngers within knife protections (B).
Doing so may result in injury.
Clearing misfeed(s)
RCT Module
