Plockmatic BLM 35 - Cleaning the Rotator Rollers (2 X); Cleaning the Paper Path Sensors (5 X)

108 pages

Save Page as PDF

To Next Page

To Previous Page

continued on next page

Cleaning the rotator rollers (2x)

Rotator rollers

Also clean the idler rollers

Cleaning the paper path sensors (5x)

Knife guardsExit sensor

Infeed

sensor

WARNING

Do not place your ngers inside the knife guards.

Doing so may result in injury.
