POFUNG BF9500 - Menu Item List

BF9500 车载台使用说明书
1） According to the menu operation flow into the content editor interface(Menu No.10 and Menu No.21)；
2） Scintillation screen "_", rotate the knob switch or Mic's key, and select the desired content, short
press confirm to save the current character and into the next character editing, short press confirm the current
character (not save) and into the next character editing, short press move to the left a character editor, short
press button to delete the cursor and on the right side of the content.When the cursor is at the far left short
press automatic save and exit is set to the main interface, When the cursor at the far right position and the without
setting content and press the key does not automatically save and return to the higher level menu interface, When
the cursor at the far right position and the without setting content and press the key to save and return to the higher
level menu interface.
■Menu item list 菜单项列表
Menu
Display
Function
option
default
1
STP.
Frequency step
2.5、5、6.25、8.33、10、12.5、
20、25、50、100K
6.25K
2
SPK.
Horn open mode
SQ、CTC、TON、C*T、C/T
SQ
3
2TONE
2TONE signaling group
00～31
00
4
5TONE
5TONE signaling group
00～49
00
5
DTMF
DTMF signaling group
0～9
0
6
FMN.
Narrow-band switch
ON、OFF
OFF
7
TX.
Launch
ON、OFF
ON
8
BCL.
busy channel lockout
ON、OFF
OFF
9
TALK.
Talk Around
ON、OF
OF
10
M.NAME
Editing Channel Name
11
BS.
Beat Frequency
ON、OFF
OFF
12
L. OUT.
Scan skip
ON、OFF
OFF
13
COMP.
Voice Compander
ON、OF
OF
14
SCR.
Scrambler setup
ON、OFF
OFF
15
MDF.
Channel display mode
MN、FRQ
MN
16
D.
Radio's DTMF SELF ID
ENQUIRY
12345
17
F.
Radio's 5TONE SELF ID
ENQUIRY
12345
18
BP.
Voice Prompt
ON、OFF
OFF
19
TOT.
Time-out timer
OFF、1～30 分钟
3
20
APO.
Auto power off
OFF、0.5H、1H、1.5H、2H、4H
OFF
