BF9500 车载台使用说明书
1) Route the DC power cable supplied with the transceiver directly to the vehicle's battery terminals using the shortest path
from the transceiver.
·We recommend you do not use the cigarette lighter socket as some cigarette lighter sockets introduce an unacceptable voltage
drop.
·The entire length of the cable must be dressed so it is isolated from heat, moisture, and the engine secondary (high voltage)
ignition system/ cables.
2) After installing cable, in order to avoid the risk of damp, please use heat-resistant tap to tie together with fuse box. Don't
forget to reinforce whole cable.
3) In order to avoid the risk of short circuit, please cut down connection with negative of battery, then connect with radio.
4) Confirm the correct polarity of the connections, then attach the power cable to the battery terminals; red connects to the
positive terminal and black connects to the negative terminal.
·Use the full length of the cable without cutting off excess even if the cable is longer than required. In particular, never remove
the fuse holders from the cable.
5) Reconnect any wiring removed from the negative terminal.
6) Connect the DC power cable to the transceiver's power supplym connector.
·Press the connectors firmly together until the locking tab clicks.
2. Fixed Station Operation
