Point Grey Flea3 GigE Technical Reference C GenICam Features
Name Display Name Description Value
ReverseX Reverse X
Flip horizontally the image sent by the device. The AOI is applied
after the flip
True
False
PixelFormat Pixel Format Format of the pixel data (not all cameras support all formats)
Mono8,
Mono12,
Mono16,
Raw8,
Raw12,
Raw16,
RGB,
YUV411,
YUV422
PixelCoding Pixel Coding Coding of the pixels in the image
Mono
Raw
YUV
RGB
PixelSize Pixel Size Size of a pixel in bits 8/12/16/24
PixelColorFilter Pixel Color Filter Type of color filter that is applied to the image
TestImageSelector
Test Image
Selector
Selects the type of test image that is sent by the camera
Off
Test Image 1
Test Image 2
VideoMode Video Mode Current video mode 0 ... 8
PixelBigEndian Pixel BigEndian Set the pixel endianess for pixel format Mono16
True
False
BinningHorizontal Binning Horizontal Number of horizontal pixels to combine together
BinningVertical Binning Vertical Number of vertical pixels to combine together
PixelDynamicRangeMin
Dynamic Range
Min
Indicates the minimum pixel value transferred from the camera
PixelDynamicRangeMax
Dynamic Range
Max
Indicates the maximum pixel value transferred from the camera
C.4 Acquisition Control
Name Display Name Description Value
AcquisitionMode Acquisition Mode
Sets the acquisition mode of the
device
Continuous
Single Frame
Multi Frame
AcquisitionStart Acquisition Start
Starts the acquisition of the
device
Write Only
AcquisitionStop AcquisitionStop
Stops the acquisition of the device
at the end of the current frame
Write Only
AcquisitionFrameCount Acquisition Frame Count
Number of frames to acquire in
Multi Frame acquisition mode
AcquisitionFrameRate Acquisition Frame Rate (Hz)
Controls the acquisition rate (in
Hertz) at which the frames are
captured
