Point Grey Flea3 GigE - FL3-GE-20 S4 Video Modes and Frame Rates

Point Grey Flea3 GigE Technical Reference 8 Flea3 GigE Attributes
8.4.6 FL3-GE-20S4 Video Modes and Frame Rates
Table 8.9: FL3-GE-20S4M Frame Rates
Pixel Format 1624 x 1224 1600 x 1200 1280 x 960 640 x 480 320 x 240 160 x 120
8-bit (Mono) 15 15 19 32 48 66
12-bit (Mono) 14 15 19 32 48 66
16-bit (Mono) 11 11 17 32 48 66
Mode 0
Pixel Format 812 x 612 640 x 480 320 x 240 160 x 120
All Formats 28 32 48 65
Mode 1
Pixel Format 404 x 306 320 x 240 160 x 120
All Formats 46 50 62
Mode 5
Pixel Format 1624 x 1224 1600 x 1200 1280 x 960 640 x 480 320 x 240 160 x 120
8-bit (Mono) 15 15 19 32 48 66
12-bit (Mono) 14 15 19 32 48 66
16-bit (Mono) 11 11 17 32 48 66
Mode 7
Images acquired by color cameras using Mono8, Mono12 or Mono16 modes are converted to
greyscale on the camera. Users interested in accessing the raw Bayer data to apply their own color
conversion algorithm or one of the FlyCapture library algorithms should refer to Accessing Raw
Bayer Data on page 81.
Table 8.10: FL3-GE-20S4C Frame Rates
Pixel Format 1624 x 1224 1600 x 1200
1280 x
960
640 x
480
320 x 240 160 x 120
8-bit (Mono, Raw) 15 15 19 32 48 66
12-bit (Mono, Raw, YUV411) 14 15 19 32 48 66
16-bit (Mono, Raw, YUV422) 11 11 17 32 48 66
24-bit (YUV444, RGB) 7 7.5 11.5 32 48 66
Mode 0
Pixel Format 812 x 612 640 x 480 320 x 240 160 x 120
All Formats 15 19 32 48
Mode 1
Pixel Format 812 x 612 640 x 480 320 x 240 160 x 120
All Formats 28 32 48 65
Mode 4
Pixel Format 404 x 306 320 x 240 160 x 120
All Formats 15 19 32
Mode 5
Revised 10/29/2013
Copyright ©2010-2013 Point Grey Research Inc.
63
