Point Grey Flea3 GigE Technical Reference 4 Flea3 GigE Physical Interface
4.6 Infrared Cut-Off Filters
Point Grey color camera models are equipped with an additional infrared (IR) cut-off filter. This filter can reduce
sensitivity in the near infrared spectrum and help prevent smearing. The properties of this filter are illustrated in the
results below.
Figure 4.3: IR filter transmittance graph
In monochrome models, the IR filter is replaced with a transparent piece of glass.
The following are the properties of the IR filter/protective glass:
Type Reflective
Material Schott D 263 T
Physical Filter Size 14 mm x 14 mm
Glass Thickness 1.0 mm ±0.07 mm
Dimensional Tolerance ±0.08 mm
For more information, see Dust Protection.
Title Article
Removing the IR filter from a color camera Knowledge Base Article 215
Related Knowledge Base Articles
Revised 10/29/2013
Copyright ©2010-2013 Point Grey Research Inc.
