Point Grey Flea3 GigE Technical Reference 8 Flea3 GigE Attributes
8.3 GenICam Image Format Control
Name Display Name Description Value
SensorWidth Sensor Width Effective width of the sensor in pixels
SensorHeight Sensor Height Effective height of the sensor in pixels
MaxWidth Max Width Maximum width of the image in pixels
MaxHeight Max Height Maximum height of the image in pixels
Width Width Width of the image provided by the device in pixels
Height Height Height of the image provided by the device in pixels
OffsetX Offset X Vertical offset from the origin to the AOI in pixels
OffsetY Offset Y Horizontal offset from the origin to the AOI in pixels
ReverseX Reverse X
Flip horizontally the image sent by the device. The AOI is applied
after the flip
True
False
PixelFormat Pixel Format Format of the pixel data (not all cameras support all formats)
Mono8,
Mono12,
Mono16,
Raw8,
Raw12,
Raw16,
RGB,
YUV411,
YUV422
PixelCoding Pixel Coding Coding of the pixels in the image
Mono
Raw
YUV
RGB
PixelSize Pixel Size Size of a pixel in bits 8/12/16/24
PixelColorFilter Pixel Color Filter Type of color filter that is applied to the image
TestImageSelector
Test Image
Selector
Selects the type of test image that is sent by the camera
Off
Test Image 1
Test Image 2
VideoMode Video Mode Current video mode 0 ... 8
PixelBigEndian Pixel BigEndian Set the pixel endianess for pixel format Mono16
True
False
BinningHorizontal Binning Horizontal Number of horizontal pixels to combine together
BinningVertical Binning Vertical Number of vertical pixels to combine together
PixelDynamicRangeMin
Dynamic Range
Min
Indicates the minimum pixel value transferred from the camera
PixelDynamicRangeMax
Dynamic Range
Max
Indicates the maximum pixel value transferred from the camera
Revised 10/29/2013
Copyright ©2010-2013 Point Grey Research Inc.
