8.4.4 FL3-GE-13S2 Video Modes and Frame Rates
Table 8.5: FL3-GE-13S2M Frame Rates
Pixel Format 1288 x 964 1280 x 960 640 x 480 320 x 240 160 x 120
Mono8 31 31 52 82 116
Mono12 23 23 52 82 116
Mono16 17 17 52 82 116
Mode 0
Pixel Format 644 x 482 640 x 480 320 x 240 160 x 120
All Formats 58 58 88 120
Mode 1
Pixel Format 1288 x 964 1280 x 960 640 x 480 320 x 240 160 x 120
All Formats 16 16 27 42 58
Mode 7
Images acquired by color cameras using Mono8, Mono12 or Mono16 modes are converted to
greyscale on the camera. Users interested in accessing the raw Bayer data to apply their own color
conversion algorithm or one of the FlyCapture library algorithms should refer to Accessing Raw
Bayer Data on page 81.
Table 8.6: FL3-GE-13S2C Frame Rates
Pixel Format 1288 x 964 1280 x 960 640 x 480 320 x 240 160 x 120
8-bit (Mono, Raw) 31 31 52 82 116
12-bit (Mono, Raw, YUV411) 23 23 52 82 116
16-bit (Mono, Raw, YUV422 17 17 52 82 116
24-bit (YUV444, RGB) 11.5 11.5 46 82 116
Mode 0
Pixel Format 644 x 482 640 x 480 320 x 240 160 x 120
All Formats 31 31 52 82
Mode 1
Pixel Format 644 x 482 640 x 480 320 x 240 160 x 120
8-, 12-, 16-bit (Mono) 58 58 88 120
8-, 12-, 16-bit (Raw, YUV411, YUV422) 54 54 82 112
24-bit (YUV444, RGB) 46 46 82 112
Mode 4
Pixel Format 1288 x 964 1280 x 960 640 x 480 320 x 240 160 x 120
8-, 12-, 16-bit (Mono, Raw, YUV411, YUV422) 16 16 27 42 58
24-bit (YUV444, RGB) 11.5 11.5 27 42 58
Mode 7
