Point Grey Flea3 GigE Technical Reference 8 Flea3 GigE Attributes
8.4.7 FL3-GE-28S4 Video Modes and Frame Rates
Table 8.11: FL3-GE-28S4M Frame Rates
Pixel Format 1928 x 1448 1600 x 1200 1280 x 960 640 x 480 320 x 240 160 x 120
8-bit (Mono) 15 17 19 28 36 44
12-bit (Mono) 10 15 19 28 36 44
16-bit (Mono) 7.5 11 17 28 36 44
Mode 0
Pixel Format 964 x 724 640 x 480 320 x 240 160 x 120
All Formats 27 32 38 44
Mode 1
Pixel Format 480 x 362 320 x 240 160 x 120
All Formats 45 45 45
Mode 5
Pixel Format 1928 x 1448 1600 x 1200 1280 x 960 640 x 480 320 x 240 160 x 120
8-bit (Mono) 9 10.5 12 18 23 28
12-bit (Mono) 9 10.5 12 18 23 28
16-bit (Mono) 7.5 10.5 12 18 23 28
Mode 7
Images acquired by color cameras using Mono8, Mono12 or Mono16 modes are converted to
greyscale on the camera. Users interested in accessing the raw Bayer data to apply their own color
conversion algorithm or one of the FlyCapture library algorithms should refer to Accessing Raw
Bayer Data on page 81.
Table 8.12: FL3-GE-28S4C Frame Rates
Pixel Format 1928 x 1448 1600 x 1200 1280 x 960 640 x 480 320 x 240 160 x 120
8-, 12-, 16-bit (Mono, Raw,
YUV411, YUV422)
15 17 19 28 36 44
24-bit (YUV444, RGB) 10.5 15 19 28 36 44
Mode 0
Pixel Format 964 x 724 640 x 480 320 x 240 160 x 120
All Formats 15 19 28 36
Mode 1
Pixel Format 964 x 724 640 x 480 320 x 240 160 x 120
All Formats 27 32 38 44
Mode 4
Pixel Format 480 x 362 320 x 240 160 x 120
All Formats 14 19 28
Mode 5
Revised 10/29/2013
