Point Grey Flea3 GigE Technical Reference E Control and Status Registers
Offset Name Field Bit Description
80028h
Bank_7_
Offset_Inq
Bank_7_Quadlet_Offset [0-31] 32-bit offset of Bank 7 table data
8002Ch
Bank_8_
Offset_Inq
Bank_8_Quadlet_Offset [0-31] 32-bit offset of Bank 8 table data
80030h
Bank_9_
Offset_Inq
Bank_9_Quadlet_Offset [0-31] 32-bit offset of Bank 9 table data
80034h
Bank_10_
Offset_Inq
Bank_10_Quadlet_Offset [0-31] 32-bit offset of Bank 10 table data
80038h
Bank_11_
Offset_Inq
Bank_11_Quadlet_Offset [0-31] 32-bit offset of Bank 11 table data
8003Ch
Bank_12_
Offset_Inq
Bank_12_Quadlet_Offset [0-31] 32-bit offset of Bank 12 table data
80040h
Bank_13_
Offset_Inq
Bank_13_Quadlet_Offset [0-31] 32-bit offset of Bank 13 table data
80044h
Bank_14_
Offset_Inq
Bank_14_Quadlet_Offset [0-31] 32-bit offset of Bank 14 table data
80048h
Bank_15_
Offset_Inq
Bank_15_Quadlet_Offset [0-31] 32-bit offset of Bank 15 table data
E.10 FRAME_INFO: 12F8h
Field Bit Description Frame-Specific Information
Presence_Inq [0]
Presence of this feature
0: Not Available, 1: Available
[1-5] Reserved
ROI_Pos_Inq [6]
Presence of image-specific information display
0: Not Available, 1: Available
GPIO_State_Inq [7]
Strobe_Pat_Inq [8]
Frame_Count_Inq [9]
WB_CSR_Inq [10]
Exp_CSR_Inq [11]
Bright_CSR_Inq [12]
Shutter_CSR_Inq [13]
Gain_CSR_Inq [14]
Time_Inq [15]
CSR_Abs_Value [16]
Toggles between displaying 32-bit relative or absolute CSR values. If absolute value not
supported, relative value is displayed.
0: Relative, 1: Absolute
This field is currently read-only
[17-21] Reserved
