Point Grey Flea3 GigE Technical Reference 7 Image Acquisition
7 Image Acquisition
7.1 Asynchronous Triggering
The camera supports asynchronous triggering, which allows the start of exposure (shutter) to be initiated by an external
electrical source (or hardware trigger) or from an internal software mechanism (software trigger).
Flea3 GigE Supported Trigger Modes
Model Mode
All Standard External Trigger (Mode 0)
All Bulb Shutter Trigger (Mode 1)
All Skip Frames Trigger (Mode 3)
All Multiple Exposure Preset Trigger (Mode 4)
All Multiple Exposure Pulse Width Trigger (Mode 5)
FL3-GE-13S2
FL3-GE-28S4
Low Smear Trigger (Mode 13)
All Overlapped Exposure Readout Trigger (Mode 14)
All Multi-Shot Trigger (Mode 15)
To access trigger modes:
n GenICam—Acquisition Control
n FlyCapture API—AsyncTriggerEx
n CSRs—TRIGGER_MODE: 830h
7.1.1 GenICam Acquisition Control
Name Display Name Description Value
AcquisitionMode Acquisition Mode
Sets the acquisition mode of the
device
Continuous
Single Frame
Multi Frame
AcquisitionStart Acquisition Start
Starts the acquisition of the
device
Write Only
AcquisitionStop AcquisitionStop
Stops the acquisition of the device
at the end of the current frame
Write Only
AcquisitionFrameCount Acquisition Frame Count
Number of frames to acquire in
Multi Frame acquisition mode
AcquisitionFrameRate Acquisition Frame Rate (Hz)
Controls the acquisition rate (in
Hertz) at which the frames are
captured
AcquisitionFrameRateControlEnabled
Acquisition Frame Rate
Control Enabled
Enables manual control of the
camera frame rate
True
False
