Point Grey Flea3 GigE Technical Reference 2 Flea3 GigE Installation
4. Configure IPSettings
After installation is complete, the Point Grey GigEConfigurator opens. This tool allows you to configure the IPsettings of
the camera and network card.
If the GigEConfigurator does not open automatically, open the tool from Start Menu>FlyCapture
SDK>Utilities>GigEConfigurator. If prompted to enable GigEenumeration, select Yes.
a. In the left pane, select the Local Area Connection corresponding to the network interface card (NIC) to which
the camera is connected.
b. In the right pane, review maximum transmission unit (MTU). If not 9000, enable jumbo frames on the NIC by
clicking Open Network Connections. (While most NICs support 9000-byte jumbo frames, this feature is often
disabled by default.)
