4.10
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
LINE / HOSE ROUTING
FUEL LINE ROUTING
• The fuel supply line
q
is routed as shown below and
retained by a clip
w
at the front engine mount.
• The fuel vent line
e
is routed as shown below and
terminates at the fuel vent connector
r
that is inserted
in the frame.
FUEL SYSTEM
