4.44
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
DIGITAL WRENCH® OPERATION
DIGITAL WRENCH® - DIAGNOSTIC CONNECTOR
The diagnostic connector
q
is located under the front console, under the steering column as shown.
DIGITAL WRENCH® DIAGNOSTIC SOFTWARE OVERVIEW
NOTE
Refer to Section 2, 3 and 4 in the Instruction Manual provided in the Digital Wrench® Diagnostic Kit to install the
Polaris Digital Wrench® diagnostic software on your computer.
The Digital Wrench® diagnostic software allows the technician to perform the following tests and observations:
• View or clear trouble codes
• Analyze real-time engine data
• Reflash ECU calibration files
• Perform guided diagnostic procedures
• Create customer service account records
• Perform output state control tests (some models)
FUEL SYSTEM
