Polaris RANGER ETX INTL 2015 User Manual

7
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
7.3
GENERAL INFORMATION
SPECIAL TOOLS
PART
NUMBER
TOOL DESCRIPTION
2872608 Roll Pin Removal Tool
PU-48951
or 8700226
CV Boot Clamp Tool
Bosch Automotive Service Solutions: 1-800-345-2233
or http://polaris.service-solutions.com
FINAL DRIVE TORQUE TABLE
ITEM SPECIFICATION
Brake Caliper Mount Bolt 46 ft-lbs (62 Nm)
Front Hub Castle Nut
90 ft-lbs (122 Nm)
Rear Hub Castle Nut
110 ft-lbs (150 Nm)
Prop Shaft Support
Bearing Fasteners
36 ft-lbs (49 Nm)
Prop Shaft Bearing Set
Screws
35 in-lbs (4 Nm)
Wheel Lug Nuts (Steel
Wheels)
36 ft-lbs (49 Nm)
Wheel Lug Nuts
(Aluminum Wheels)
30 ft-lbs + 90º (41 Nm +
90º)
FINAL DRIVE
